Japanese engine 3t diesel forklift truck with 4.5 m mast

2~3.5ton Small capacity container diesel forklift side shift triplex mast IC forklift
Availability:
Quantity:
  • CPCD30
  • Shangqi

Japanese engine 3t diesel forklift truck with 4.5 m mast

2-3.5t内燃叉车

Product Description

2~3.5 ton diesel forklift can provide strong driving force and sensitive operation experience.  Completing with beautiful appearance, good quality and reasonable price, it is definitely your good choice for material handling job for both indoor and outdoor. It is widely used in plants, office buildings, libraries, hotels,restaurants, logistics and other material handling industry.

2-3.5T内燃叉车

Product Characteristics

Product

Selling Point

2 ton~3.5 ton diesel forklift


 Streamlined design

 Safety and comfortable cab

 Optional engine and transmission

 Long service life solid tires

Optional side shift device

Automatic transmission


外形尺寸图

2-3.5T内燃叉车技术参数

Data Sheet

Model

CPCD20

CPCD25

CPCD30

CPCD35

Power type

Diesel/Gasoline/LPG

Rated Capacity

2000kg

2500kg

3000kg

3500kg

Load Centre

500mm

500mm

500mm

500mm

Lift Height

3000mm~6000mm

Mast

Full free duplex or triplex mast

Fork Size (L×W×T)

1070×120×40mm

1070×120×45mm

1070×125×45mm

1070×130×45mm

Length to fork face

2589mm

2644mm

2744mm

2839mm

Overall Width

1150mm

1150mm

1236mm

1236mm

Overhead Guard Height

2145mm

2145mm

2175mm

2175mm

Min.turning Radius

2220mm

2290mm

2400mm

2490mm

Travel speed(full loaded/unloaded)

17/19km/h

17/19km/h

18/19km/h

18/19km/h

Lift speed

470mm/sec

470mm/sec

430mm/sec

400mm/sec

Max. gradeability

20%

20%

20%

15%

Wheelbase

1650mm

1650mm

1700mm

1750mm

Diesel Engine

Xinchang/ISUZU/Mitsubishi/Yanmar/Nissan

Company Profile

公司正门


Jiangsu Shangqi Heavy Industry Technology Co. Ltd is a wholly-owned subsidiary of Jiangsu Shangqi Group. It was established in 2002 and is located in the economic development zone of Jiangsu city, enjoying convenient transportation and beautiful environment. Our company covers an area of 250000 square meters and has more than 500 employees, including over 100 employees for technical and quality control. We are specialized in the research, development, sale and service of wheel loaders, mini excavators, forklifts and related products. We have obtained ISO9001 certificate and Special Equipment Production license. Most of our products have got CE certificates. In addition, Our company has a number of invention patents and core technology, has the key equipment for mass production of products, to meet the needs of customers with high grade and high reliability products. Our multi-function wheel loader has occupied the largest sales volume in the domestic similar export products for many years and has been exported to more than 50 countries and regions in the world.

设备2

Certification


CPC(Q)D2040-ON

CE CETIFICATE

CPC(Q)D2040-ATTACK1

CE CERTIFICATE

重工质量体系证书(英文正本)

ISO

FAQ


1,Are you original manufacture?

Yes,we are a leading manufacturer in construction machinery in China.

2,What kind terms of payment can be accepted?

Normally we can work on T/T or L/C term.

3,What about the delivery time?

7-30 days after receiving the deposit.

4,what about the warranty time?

1 year after shipment.
